Offline X-Ray Point Material System CX7000L
Japan Union offline X-Ray fully automatic point material machine CX7000L automatic coding and anti-mistake labeling.
Keyword:
Classification:
Spotting System X-Ray
Contact E-mail
Contact Phone
Main Features
Nihon Rengou Offline X-Ray Fully Automatic Counting Machine CX7000L Automatic Coding and Foolproof Labeling.
Intelligent Counting Machine
The offline X-Ray counting system CX7000L can quickly and accurately detect materials such as 7-17 inch trays/Jedec Tray IC moisture-sensitive packages.
Convenient for employees to operate, reducing workspace.
Automatic coding and foolproof labeling.
Supports integration with ERP, MES, and WMMS systems.
CX7000L
Offline X-Ray Counting System
Permission Management and Real-time Radiation Monitoring
Intelligent Anti-Interference Counting Algorithm
Tray Sensing, Error-proof Labeling
AI Intelligent Recognition, Detecting Various Materials
Nihon Rengou Technology Offline X-Ray Counting System CX7000L
This device is a beautifully designed, high-tech offline X-Ray counting system that can cover all resistive and capacitive materials as well as IC materials, enabling rapid counting and inventory of various types of trays.
Technical Parameters
| Overall Status | ||||||||
| Size | 800(W)*1380(D)*1950(H)mm | Packing Weight | Approximately 746kg | |||||
| Weight | 674kg | Power Voltage | 220AC/50Hz | |||||
| Packing Size | Approximately 900(W)*1460(D)*2090(H)mm | Power | Max.1.5kW | |||||
| X-ray Source (50kV/80kV optional) | ||||||||
| Tube Voltage | 50kV | Tube Voltage | 80kV | |||||
| Tube Type | Closed Type | Tube Type | Closed Type | |||||
| Tube Current | 1000μA | Tube Current | 700μA | |||||
| Focal Size | 0.07mm | Focal Size | 0.03mm | |||||
| Imaging System | ||||||||
| Detector | High Definition FPD | Pixel Size | 139μm | |||||
| Effective Detection Size | 430*430[mm] | Frame Rate | 2fps | |||||
| Pixel Matrix | 3072*3072[pixel] | AD Conversion Bit Depth | 16bits | |||||
| Detection Capability | Industrial Computer | |||||||
| Roll Material Size | 7"-17" Tape Reel | Display | Built-in 27-inch HD Display | |||||
| Tray Height | ≤80mm | Operating System | Windows 10 64-bit | |||||
| Minimum Material Specification | 01005 | Hard Disk | 1TB+256ssd | |||||
| Detection Accuracy | 99.99% | Memory | 16G | |||||
| Detection Time | Detection time for 7"~17" trays is less than 10s/tray Detection time for 7"*4 trays is less than 10s |
CPU Specification | i7 | |||||
| Supports integration with MES, ERP and WMS intelligent warehousing systems | ||||||||
| Others | ||||||||
| Door Opening Method | Load-bearing Automatic Door | Radiation Level | ≤0.5μSv/h | |||||
| Detection Method | Offline | Energy Monitoring | Safety Protection, Real-time Radiation Monitoring | |||||
| Feeding Method | Manual | Permission Management | Supports dual-channel entry with Password and Fingerprint | |||||
Note: This information only represents general descriptions and features, and may change with technological advancements and equipment upgrades. Specific parameters are subject to the final agreement.
 |
 |
 |
